Fox ESS 5kW F Series 1PH Dual Tracker PV Inverter

#2 FE-F5000

FE-F5kW Datasheet

FE-F5kW User Manual

FE-F5kW Installation Guide

FE-F5kW G99 Certification

Fox ESS F Series Dual-MPPT Solar Inverter – 5kW

Part No: [Insert Part No] | Category: Solar Inverters

---

⚡ High-Performance 5kW Solar Inverter with Dual-MPPT

The Fox ESS F Series 5kW Inverter is a compact, high-performance solution designed to maximise your solar energy output. With dual-MPPT tracking, an IP65 weatherproof rating, and seamless battery compatibility, this inverter is built for both performance and durability.

Featuring an ultra-low start-up voltage of 120V, the F Series ensures maximum energy harvest even in low-light conditions. It is also smart-enabled, allowing you to monitor and control your solar system remotely via the FoxESS smartphone app or web portal.

---

🌞 Key Features

• ✔️ High efficiency – up to 97.4%

• ✔️ Dual-MPPT design for optimised energy harvest

• ✔️ Ultra-low start-up voltage (120V)

• ✔️ Plug & Play installation – flexible configuration

• ✔️ IP65-rated enclosure – safe for outdoor use

• ✔️ Remote monitoring via FoxESS Cloud & smartphone app

• ✔️ Compatible with Fox battery storage (with Fox charge controller)

• ✔️ Future-proof upgrade path to hybrid systems

⚠️ Collections are not permitted due to health & safety regulations.

---

📦 Technical Specifications

• Weight: 15.5 kg

• Rated Power: 5,000 W

• MPPT Quantity: 2 (Dual MPPT)

• Min PPT Voltage: 120 V

• Max PPT Voltage: 600 V

• DC Startup Voltage: 120 V

• DC Shutdown Voltage: 601 V

• Max Input Voltage: 600 V

• Max DC Power: 7,500 W

• Max AC Power (5 Minutes): 5,000 W

• Surge AC Power (1 Second): 0 W

• Max DC Current: 25 A

• Max DC Inputs: 2

• DC Fuses: 0

• Connector Type: MC4

• Included Connectors: 0

• Euro Efficiency: 96.8%

• Transformer: HF

• Integrated DC Switch: Yes

• Standard Warranty: 5 years (extendable to 10 years upon online registration)

---

✅ Why Choose the Fox ESS F Series 5kW?

• Ideal for residential solar PV systems

• Dual-MPPT design reduces mismatch losses

• Durable IP65 build for long-term outdoor installation

• Remote monitoring for peace of mind and control

• Backed by Fox ESS quality and extended warranty
