SDM120D Single-Phase Energy Meter – Direct Connection with Backlight

Monitor your low-amp AC circuits efficiently with the SDM120D Single-Phase Energy Meter. This reliable meter provides accurate readings for residential or light commercial applications and is ideal for installations where cost-effective metering is required.

---

Key Features

• Direct Connection: Measures up to 45A AC without the need for current transformers

• Single Direction Measurement: Tracks active energy accurately

• Backlit Display: SDM120DB version includes a backlight for easy reading in low-light conditions

• Pulse Output: Facilitates integration with monitoring systems

• Compact Design: 1 module wide for space-saving installations

• DIN Rail Mounted: Fits standard 35mm DIN rails for professional installation

---

Specifications

• Dimensions: H 119mm × W 17.5mm × D 62mm

• Maximum Load: 45A AC

• Mounting: DIN rail (requires DIN rail enclosure)

• Energy Measured: Active energy only

---

Why Choose SDM120D?

• Cost-Effective Metering: Perfect for low-amp circuits without compromising accuracy

• Easy Installation: Slim DIN rail design saves panel space

• Reliable Performance: Backlight version ensures readings are easy to take anytime
