Fox ESS 6kW F Series 1PH Dual Tracker PV Inverter

#2 FE-F6000

FE-F6kW Datasheet

FE-F6kW User Manual

FE-F6kW Installation Guide

FE-F6kW G99 Certification

Fox F Series Dual-MPPT PV Inverter – 3.0 to 6.0kW

The Fox F Series is a high-performance Dual-MPPT PV inverter range designed to optimise solar energy production for residential and small commercial installations. Available in models from 3.0kW to 6.0kW, these inverters feature low start-up voltage, a wide voltage range, and up to 97.4% efficiency, delivering maximum energy from your solar panels.

With IP65 protection and compatibility with battery storage via the Fox ESS charge controller, the F Series offers flexible installation and a future-proof solar energy solution.

---

Key Features

• ✅ High Performance – low start-up voltage and wide input range for maximum energy harvesting

• ✅ Easy Installation – plug-and-play setup with flexible configuration

• ✅ IP65 Rated – suitable for outdoor installation, built to last

• ✅ Remote Monitoring – track system performance via smartphone app or web portal

• ✅ Battery Integration Ready – compatible with Fox ESS charge controller for seamless energy storage upgrades

• ✅ Warranty – 10 years when registered online, otherwise 5 years standard

---

Technical Specifications

General

• Weight: 15.5 kg

• Rated Power: 6,000 W

• Euro Efficiency: 96.8%

• Warranty: 5 years standard / 10 years when registered

• Transformer: HF

Voltage & Current

• Min PPT Voltage: 120 V

• Max PPT Voltage: 600 V

• DC Startup Voltage: 120 V

• DC Shutdown Voltage: 601 V

• Max Input Voltage: 600 V

• Max DC Power: 9,000 W

• Max AC Power (5 Minutes): 6,000 W

• Surge AC Power (1 Second): 0 W

• Max DC Current: 25 A

Connections & MPPT

• Max DC Inputs: 2

• Connector Type: MC4

• Included Connectors: 0

• DC Fuses: 0

• MPPT Quantity: 2

• Integrated DC Switch: Yes

---

Why Choose the Fox F Series Inverter?

• Delivers reliable, efficient solar conversion for small-to-medium installations

• Supports future battery integration for energy storage upgrades

• Compact, lightweight, and easy to install

• Monitor performance remotely via app or web portal

• IP65-rated design ensures durability in outdoor environments

---

✅ The Fox F Series Dual-MPPT PV Inverter is a versatile, high-efficiency solution for modern solar systems, offering flexibility, durability, and seamless integration with battery storage.
